Casemet Cubo E wall cabinet is ideal as a switch box or electrical cabinet
The Casemet standard enclosure series Cubo E wall cabinets are ideal for protecting electromechanical components due to their properties – they are a good choice for electrical cabinets or switch cabinets. The enclosure's features, such as high IP and IK classes, a wide range of sizes and a latched door, offer many different usage and customization options.
Cubo E cabinets:
- Protection class: IP 66, IP 55 with two doors
- Impact resistance: IK 09 (-25 °C... +35 °C)
- Material options:
- Polyester-painted steel
- Stainless steel AISI304
- Stainless steel AISI316L
- Latch/lock-mounted door
- Flange openings in polyester-painted (RAL 7035) cabinets, smooth sides in stainless steel cabinets
- Available in 40 sizes
- Gasket: PUR (polyurethane)
- Mounting plate: Galvanized steel
- Hinges: Stainless steel
- Locks: Zinc die-cast with chrome coating in painted cabinets and the same material as the cabinet in AISI304 or AISI316L steel cabinets
- Door opens 110 degrees
- Door can be switched
"Customized Cubo E enclosure is suitable for a wide range of applications. Here, the Cubo E enclosure has been customized with customer-specific dimensions, openings and additional mounting points. This allows the enclosure to fully meet the customer's needs. Cubo E also has an extensive range of accessories, including rain covers, DIN rails, cover plates and flanges, as well as various locks and latches," says Ari Karjalainen, Sales Manager at Casemet Group.
Photo: Sales Manager Ari Karjalainen presents customized base part of Cubo E enclosure, which has just arrived from welding.
Casemet's sales team helps customers choose the right enclosure solution and customization - always taking into account the customer's wishes and the requirements set by the operating and environmental conditions!
Cubo E compliance:
Ask our sales team for more information about our enclosure solutions and accessories:
